Application
- Particularly suitable in built-up areas where foundation work needs to be vibration-free and/or low-noise.
- Highly effective in areas with sandy soil up to the surface. Due to the short required reinforcement and high production rate, it’s an economical type of pile.
- Can be used as a pile wall by screwing the piles directly next to each other, creating a vibration-free retaining wall.
- A good alternative in areas with solid topsoil layers where traditional piling could lead to pile breakage.
Features
- Rapid delivery times possible.
- Limited possibility for adjustments in pile specification until just before the start of work.
- The piles can be loaded both in compression and tension.
- Under certain conditions, piles can be directly finished to the desired height.
- The pile system is not soil-displacing.
- Concrete screw piles can be reinforced along their entire length. For longer pile lengths, a central rod is used.
- The pile system is known and accepted by the Building and Housing Supervision Service, structural engineers, and in building standards.
- Installed vibration-free and with low noise.
This soil-removing foundation technique is applied in residential and utility construction where specific soil conditions are present.
Concrete screw piles are produced in lengths up to 26 meters, and specific requests are accommodated.
Quality Control
Vroom Funderingstechnieken manufactures concrete screw piles according to its own execution procedure established as part of internal quality control and nationally applicable standards.
The manufactured concrete screw piles can optionally be acoustically measured and then assessed by an independent advisory bureau. Thanks to its own quality control, appropriate responses can be made in case of doubts about pile quality or client requests regarding execution.
Concrete for concrete screw piles is sourced from certified concrete plants.
