Vroom Funderingstechnieken offers a comprehensive package of pile systems and prefabricated concrete structures. As we are all-rounders, we can offer potential economic alternatives to arrive at a sophisticated concept. If desired, we design and calculate the proposed foundation construction. Below is an overview of our capabilities.

Vibro piles type HBF
Cast-in-situ piles

Vibro piles type HBF

Highly suitable for projects in residential construction, commercial construction, infrastructure, and the energy sector. Can be produced in large lengths and the delivery time is always short. Pre-drilling reduces pile-driving vibrations and a sound barrier during execution provides considerable noise reduction.
Vibro-combi piles
Cast-in-situ piles

Vibro-combi piles

Used for underground construction such as tunneling, parking garages, and other projects where the pile heads need to be installed below the ground level. Vibro-combi piles have the same geotechnical bearing capacity and characteristics as vibro piles type HBF.
Vibro-SD piles
Cast-in-situ piles

Vibro-SD piles

These in-ground formed and soil-displacing piles can be applied under floors in industrial halls and under pile mats. The combination of the pile and floor can lead to an economical design. The vibro-SD piles are installed at a very high production rate.
DPA screw piles
Cast-in-situ piles, Low-vibration and low-noise piles

DPA screw piles

This is an in-ground formed and soil-displacing screw pile system, with limited excavated soil. The production is low-vibration and very well suited for foundations near adjacent structures that are sensitive to settlements and/or vibrations.
DPA-PLUS screw piles
Cast-in-situ piles, Low-vibration and low-noise piles

DPA-PLUS screw piles

An in-ground formed and soil-displacing screwed pile system. Soil is laterally displaced, with only the drilling tube containing excavated soil. The production is low-vibration and very well suited for foundations near adjacent structures that are sensitive to settlements and/or vibrations.
DPA-combi screw piles
Cast-in-situ piles, Low-vibration and low-noise piles

DPA-combi screw piles

A soil-displacing screw pile system formed in the ground and equipped with a prefabricated pile core. The soil is displaced laterally, with drilling soil contained only within the drill pipe. The production process is low-vibration, making it highly suitable for foundations near buildings that are sensitive to damage from settlements and/or vibrations.
HEK screw piles
Cast-in-situ piles, Low-vibration and low-noise piles

HEK screw piles

An in-ground formed and fully soil-displacing pile system. Applied in projects where vibration-free and/or low-noise production is required for the surrounding environment. Suitable for foundations near adjacent properties and existing (residential) construction, which are sensitive to settlements and/or vibrations.
HEK-combi screw piles
Cast-in-situ piles, Low-vibration and low-noise piles

HEK-combi screw piles

All the relevant features and geotechnical bearing capacity of HEK screw piles, but with a prefabricated concrete element. Suitable for underground construction, such as tunneling, parking garages, and other projects where the pile heads are installed deep beneath the ground level.
Concrete screw piles
Cast-in-situ piles, Low-vibration and low-noise piles

Concrete screw piles

Developed for projects on sandy soil and also applicable to other specific soil conditions. This pile system is non-soil-displacing and has a high production speed. The production is vibration-free and low-noise, making it suitable for foundations near adjacent structures.
Tubular screw piles
Cast-in-situ piles, Low-vibration and low-noise piles

Tubular screw piles

Developed for projects in a specific soil condition where full-length reinforcement is required. The pile system is non-displacing and has a high production speed. Production is vibration-free and low-noise, making it suitable for foundation work near neighboring structures.
Precast driven piles (concrete)
Precast driven piles

Precast driven piles (concrete)

Over the decades, a wealth of experience has been accumulated in the use of precast driven piles for foundations, which is still widely employed. The pile system displaces soil. In addition to smaller projects, we specialize in foundation work using heavy, large-sized precast driven piles.
HPS (Hollow Precast Screw Pile)
Low-vibration and low-noise piles, Precast driven piles

HPS (Hollow Precast Screw Pile)

The Hollow Precast Screw Pile is a ground-displacing screwed pile system. The ground is displaced laterally at the tip, resulting in minimal soil upheaval. When screwing the pre-stressed Hollow Precast Screw Pile, a grout mixture is injected under the lost screw point.
